Type: single-axle, wheeled, dual-purpose
Overall dimensions: 2830*998*1300mm
Structural weight: 395kg with water-cooled diesel engine
Engine type: single-cylinder, vertical, water-cooled, four-stroke
Engine rated power, kw: 8.1
Rated traction force:
Mounting tire on dry land 250*9.8 (N)
Install iron wheel in paddy field 180X9.8(N)
Road clearance: final drive case bottom 247(mm) gearbox middle 315(mm)
Wheelbase: 1450~1500 (mm)
Tractor gearbox gears and theoretical speeds: (Engine speed is 2300r/min)
