Product

4YZ‑6B PLUS
4YZ‑6B PLUS - Image 2
4YZ‑6B PLUS - Image 3
4YZ‑6B PLUS - Image 4
4YZ‑6B PLUS - Image 5

4YZ‑6B PLUS

Item Unit Specification
Model Designation / 4YZ‑6B PLUS Self‑propelled Corn Harvester
Structure Type / Self‑propelled wheel‑type
Function Type / Ear harvesting + husking + straw returning to field
Matched Engine Type / In‑line, 6‑cylinder, water‑cooled, electronic fuel injection
Engine Rated Power / Rated Net Power kW 191 / 191.5
Overall Dimensions (L×W×H) mm 650 mm row spacing: 8800×4100×3710;
630 mm: 8800×4000×3710;
580 mm: 8800×3750×3710;
550 mm: 8800×3600×3710
Machine Weight kg 650 mm: 10720; 630 mm: 10640; 580 mm: 10540; 550 mm: 10460
Working Rows rows 6
Row Spacing mm 650 (optional 630 / 580 / 550)
Working Width mm 3826 (optional 3726 / 3476 / 3326)
Minimum Ground Clearance mm 330
Operating Speed km/h 1.4–4.5
Add to quote
